USB Connectors

The Tyco Electronics Connector System will accommodate the two differentially driven data wires that provide bi-directional, simultaneous signals for full speed 12Mbps or for low speed 1.5Mbps used in Universal Series Bus (USB) Systems. The Tyco Electronics USB System is a complete interconnection technology for I/O devices, including: keyboards, mice, game port, serial port devices, digital audio, printers, scanners, modems, joy sticks, and other telecommunication devices. Designed for outside-of-box, user friendly applications, the Tyco Electronics system consists of a single 4-position boardmount receptacle and mating cable mount overmolded plug. Boardmount receptacles are available in standard, Type B, stacked and side-by-side configurations, adding to the system’s versatility to meet all USB applications.

Product Facts

■ Plug and Play capability ■ Hot pluggable, permits attaching or detaching peripherals without power down or reboot ■ Single 4-position connector, polarized for proper orientation ■ Complete family of boardmount receptacles, including right-angle, thru-hole, thru-hole type B, side-byside, and stacked ■ Cable mount overmold plug kits for both standard and type B applications ■ Consolidates serial parallel, keyboard, mouse and game ports ■ Compatible with asynchronous and isochronous data transfer methods
