Ethernet and High-Speed D38999 KJ Connectors

KJA/KJB D38999-Style Connectors for Ethernet and High-Speed Data Rates from 100 Mbps to 10 Gbps.

From inflight entertainment, Wi-Fi streaming systems to SATCOM, ATS voice and data links, data management systems, and avionics control panels, aerospace applications are requiring higher data rates without compromising on performance. While COTS systems work for commercial applications, military and commercial aircraft require vibration-resistant, EMI shielded, and environmentally sealed solutions tested against the harshest standards.

ITT Cannon expands its KJA/KJB (D38999 III) family to include a full range of high-speed and Ethernet layouts with Twinax, Quadrax, OctoRax and OctoGig termini. This includes termini tested and design per ARINC and BACC47 specifications and EN50173 test protocols.


Features

• 100 Mbps - 10 Gbps Data Rates
• Low insertion force contacts- TwinAx, Quadrax, OctoRax, OctoGig Termini
• Environmental & non-environmental versions
• Full range of D38999 shell sizes and styles
• Tested per ARINC and BACC47 requirements

D38999-Style Ethernet and High Speed_KJ_Catalog ITT Cannon.pdf
